PLC Control Lab Testing Equipment Children Bicycle Handlebar Component Tester
| MOQ: | 1 unit |
| Price: | negoitable |
| Standard Packaging: | Plywood case |
| Delivery Period: | 35 work days |
| Payment Method: | T/T, Western Union, MoneyGram |
| Supply Capacity: | 1 unit |
Detail Information
Place of Origin
CHINA
Brand Name
SKYLINE
Certification
Calibration certificate
Model Number
SL-BC002
SKYLINE:
Children Bicycle Handlebar Component Tester
Test Force Value:
500N
Drop Height:
50mm
Loading Time:
0-999s Can Be Set
Stroke:
250mm
Air Source:
7kgf/cm2
Highlight:
abrasion testing equipment
,physical testing equipment
Product Description
Children Bicycle Handlebar Component Tester
Applications:
Children Bicycle Handlebar Component Tester is suitable for children bicycle handlebar component test. Available to test for: handle stem torque test, handle stem dead load test, handle bar and handle stem torque test.
| Test force value | 500N |
| Loading Time | 0-999s can be set |
| Stroke | 250mm |
| Controller | PLC+ touch screen control |
| Air source | 7kgf/cm2 |
Standards:
ISO 8098
GB 8098
Parameters
| Working position | 1 |
| Sample | bicycle handlebar parts (the handle bar and the handle stem) |
| Test force value | Max. 500N |
| Loading time | 0 ~ 999 s can be set |
| Stroke | 250 mm |
| Controller | PLC + touch screen control |
| Air source | 7 KGF/cm ^ 2 |
| Power supply | 1∮ AC 220V 50Hz 3A |
| Dimension (WxDxH) | 120x88x154cm |
| Weight (about) | ≈90 kg |
Applications Industry
All kinds of children bicycles can be tested on the Children Bicycle Handlebar Component Tester
