Tensile Strength Testing Machine Single Column Universal Tensile Testing Machine
| MOQ: | 1 unit |
| Price: | Negoitable |
| Standard Packaging: | Plywood case |
| Delivery Period: | 10 working days |
| Payment Method: | Western Union, T/T, MoneyGram |
| Supply Capacity: | 2 pcs/ month |
Detail Information
Place of Origin
China
Brand Name
SKYLINE
Certification
calibration certificate
Model Number
SL-T809
Skyline:
Tensile Strength Tester
Maximum Test Force:
500kg
Force Display Resolution:
1/500000
Speed Accuracy:
0.001
Speed Control Range:
0.001-510mm / Min
Weight:
85kg
Highlight:
Single Column tensile strength test equipment
,510mm/min tensile strength apparatus
,510mm/min tensile strength test equipment
Product Description
Material Lab Testing Equipment PC Controlled Single Column Universal Tensile Strength Testing Machine
Technical parameters
|
Maximum external dimensions |
520 * 450 * 1300 |
| Equipment quality | 85kg |
| Force unit | Free switching kgf, N, Lbf, KN, tf (SI), tf (long), tf (short), ozf, etc |
| Maximum test space | up and down the effective space 650mm, left and right unrestricted |
| Maximum stroke | 1000mm Other specifications can be specified 1100mm, 1200mm, 1300mm travel and so on |
| Maximum test force | 500kg |
| Force display resolution | 1/500000 |
| Force test accuracy | 0.5-1 level |
| Displacement Display Degrees | 0.0001mm |
| Speed control range | 0.001-510mm / min |
| Speed accuracy | 0.001 |
| Beam movement | the upper and lower beams move the jog function |
Material
| Base | modular sheet metal structure, easy maintenance |
| Guide column | the use of high-strength special steel |
| Column guard | the use of special high-quality aluminum alloy casting molding (by a special two-color mixing spray technology) |
| Beams | the use of high-strength special steel processing, never deformation |
