Lubricating Oil Evaporating Loss Tester ASTM D5800 Use Noack Method

Place of Origin CHINA
Brand Name SKYLINE
Certification CE , Calibration Certificate
Model Number SL-OA94
Minimum Order Quantity 1 Unit
Price negotiated
Packaging Details plywood case
Delivery Time 15 working days
Payment Terms L/C, D/P, T/T, Western Union,
Supply Ability 10 unit / month
Product Details
Applicable Standard: SH/T0059;ASTM D5800 Temperature Setting: Resolution Accuracy ±0.1℃ Temperature Accuracy ± 0.5℃
Temperature Eating Unit: Environmental Protection Light Heating Unit Vacuum Control: Vacuum Pump And Manometer Air Filter
Pressure Range: 0～25mm H20 Pressure Accuracy: Resolution Accuracy ±0.05 Mm H20 Stability Accuracy ±0.2 Mm H20
Heating Power: 2.0KW Electricity Source: AC220V±10％ 50Hz
Highlight:

Lubricating Oil Evaporating Loss Tester

,

Loss Tester ASTM D5800

,

Noack Method Evaporating Loss Tester
Product Description

Lubricating Oil Evaporating Loss Tester ASTM D5800 Base Oil Evaporation Loss Analyzer Use Noack Method

Lubricating Oil Evaporation Loss Tester B Method


Lubricating Oil Evaporating Loss Tester ASTM D5800 Use Noack Method

Standards

This instrument is applicable to ASTM D5800 B and SH/T 0059 standards for determining the evaporation loss of lubricating oil.

Features

1.The latest technology: replace A method, the test process without Wood alloy to avoid environmental dye and personnel injury.
Control mode: Embedded operating system, high-speed microprocessor control, stable and reliable work.
Touch screen: LCD display, convenient touch screen operation.
2. Safety: Built-in diagnostic program and various alarms.
3. Accuracy control: Built-in large-capacity EPROM, real-time recording of temperature and pressure values at each moment.

Technical parameters

Temperature range room temperature～300℃
Temperature setting

Resolution accuracy ±0.1℃
Temperature accuracy ± 0.5℃
Heating unit environmental protection light heating unit
vacuum control vacuum pump and manometer air filter
Pressure range 0～25mm H20
Pressure accuracy

resolution accuracy ±0.05 mm H20
Stability accuracy ±0.2 mm H20
Heating power 2.0KW
Electricity source AC220V±10％ 50Hz



Configuration List

No. Item Specification Unit Qty. Noted
1 Main body   set 1
2 Evaporation crucible, upper lid and metal bend   set 1
3 Buffer bottle and capping plug   set 2
4 Precision filter   pcs 1
5 Temperature sensor   pcs 1
6 Differential pressure gauge (with oscillating red oil)   set 1 France
7 Crucible wrench   pcs 1
8 Reamer (φ2.0) pcs 1
9 Glass stubs   set 2
10 Metal cleaning wire   pcs 1
11 Power cord   pcs 1
12 Fuse   pcs 2
13 Instruction manual   pcs 1
14 Certificate of Conformity   pcs 1
