Roller Skates Slope Impact Test Equipment , Lab Testing Machine CE Approved

Name: Roller Skates Slope Impact Test Equipment , Lab Testing Machine CE Approved
Brand: SKYLINE INSTRUMENTS CO.,LTD
SKU: SL-L23X
Price: Negotiable USD
Availability: InStock

Product Details

Place of Origin: CN

Brand Name: SKYLINE

Certification: CE

Model Number: SL-L23X

Payment & Shipping Terms

Minimum Order Quantity: 1 unit

Price: negoitable

Packaging Details: plywood case

Delivery Time: 35 work days

Payment Terms: Western Union, MoneyGram, T/T

Supply Ability: 1 pcs/ month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                abrasion testing equipment, brake testing equipment


SKYLINE:	Roller-Skate-Shoe-Impact-Testing-Equipment	Standard:	GB/T20096-2006
Load:	16kg,13.33kg,14.69kg,12.8kg,15kg	Speed:	(2.5±0.3)m/s
Grinding Wheel Test Angle:	0-15 ° Accuracy Of 1 °	Accuracy:	0.01m / S;
Name:	Lab Testing Equipment

SKYLINE:	Roller-Skate-Shoe-Impact-Testing-Equipment
Standard:	GB/T20096-2006
Load:	16kg,13.33kg,14.69kg,12.8kg,15kg
Speed:	(2.5±0.3)m/s
Grinding Wheel Test Angle:	0-15 ° Accuracy Of 1 °
Accuracy:	0.01m / S;
Name:	Lab Testing Equipment

Product Description

Footwear Testing Equipment Roller Skates Slope Impact Testing Equipment

Product features

1. With anti-secondary impact device to ensure that only one impact;
 2. Can set the number of tests and show the current number of tests;
 3. According to different types of roller shoes (double row wheel, single row wheel), configuration different Of the fixture;
 4. Speed can be adjusted to meet the requirements of different specifications of the impact of shoes;

Technical parameters

1. Can be fixed single row of roller shoes and double row of skate shoes for testing;
2. With impact devices, impact energy 0-135J Adjustable test speed, set the number of impact test, speed (0-5.0) m / s, accuracy 0.01m / s;
4. Brake frontal impact test double row A (2.5 ± 0.4) m / s, load (about) 14.69 kgfB class 60J, (2.7 ± 0.3) m / s, load (about) 16.46 kgf single row A class 50J, (2.5 ± 0.3) m / s (About) 15 kgf;
5. Wheel front impact test double row A class 90J, (3.75 ± 0.4) m / s, the load (about) 15 kgf; (4.5 ± 0.4) m / s, load (about) 13.33 kgfB class 90J, (4.5 ± 0.4) m / s, load (about) 13.33 kgfB class 90J, (2.7 ± 0.3) m / s, (3.5 ± 0.4) m / s The impact of the traveling sheet, load (approximately) 14.69 kgf;

Technical parameter:

Model		Single A1	Single A2	Double A1	Double A2	Single B1	SingleB2	Double B1	Double B2
Load		16 kg	13.33 kg	14.69 kg	12.8 kg	15 kg	14.69 kg	16.46 kg	16.46 kg
Speed		(2.5±0.3)m/s	(4.5±0.4)m/s	(3.5±0.4)m/s	(3.75±0.4)m/s	(2.0±0.2)m/s	(3.5±0.4)m/s	(2.7±0.3)m/s	(2.7±0.3)m/s
Volume (W×D×H)	Host	460 × 75 × 87 cm
Volume (W×D×H)	Control box	37 × 37 × 117 cm
Power supply		AC 220V, 50/60 HZ(According to country or designated)
