GB/T 4857.4-92 Compressive Strength Testing Machine With Microcomputer Control

Name: GB/T 4857.4-92 Compressive Strength Testing Machine With Microcomputer Control
Brand: SKYLINE
SKU: SL-E11A
Rating: 4.9 (198 reviews)

Product Details

Place of Origin: CN

Brand Name: SKYLINE

Certification: CE

Model Number: SL-E11A

Payment & Shipping Terms

Minimum Order Quantity: 1 unit

Price: Negotiable

Packaging Details: Plywood case

Delivery Time: 15 working days

Payment Terms: T/T, Western Union, MoneyGram

Supply Ability: 10 pcs/ month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                GB/T 4857.4-92 Compressive Strength Testing Machine, Microcomputer Control Compressive Strength Testing Machine, Microcomputer Control Compressive Strength Tester


SKYLINE:	Intelligent Compressive Strength Testing Machine	Machine Schedule:	800mm
Pressure Plate Size:	800800800mm	Display Resolution:	0.001N
Test Speed:	12.5mm/min	Unit Stress Switching:	MPa，kPa，kgf/cm2，lbf/in2
Power Supply :	AC220V/50HZ~60HZ 4A

SKYLINE:	Intelligent Compressive Strength Testing Machine
Machine Schedule:	800mm
Pressure Plate Size:	800800800mm
Display Resolution:	0.001N
Test Speed:	12.5mm/min
Unit Stress Switching:	MPa，kPa，kgf/cm2，lbf/in2
Power Supply :	AC220V/50HZ~60HZ 4A

Product Description

Intelligent Compressive Strength Testing Machine

Product introduction

It is the basic instrument for testing the compressive strength of corrugated boxes (packaging testing equipment). It is suitable for the compressive strength test, standard test and stacking strength test of all kinds of corrugated boxes.

Product features

1. After the test is completed, there is an automatic return function to automatically judge the crushing force and automatically save the test data
2. Three settable speeds, all Chinese LCD operation interface, and a variety of units to choose from.
3. It can input relevant data and automatically convert the compressive strength, and has its own packaging and stacking test function. The power and time can be set directly, and the machine will stop automatically after the test.
4. Three working modes:
Strength test: it can measure the maximum pressure resistance of the box.
Fixed value test: the overall performance of the box can be tested according to the set pressure.
Stacking test: according to the requirements of national standards, stacking tests under different conditions such as 12 hours and 24 hours can be carried out.

Standards:

GB/T 4857.4-92 pressure test method for transport packages
GB/T 4857.3-92 static load stacking test method for transport packages

Technical parameter:

Capacity selection	0~2T (can be customized according to customer requirements)
Accurate grade	Level 1
Control mode	Microcomputer control (optional computer operating system)
Display mode	Electronic LCD display (or computer display)
Unit switching	kgf,gf ,N,kN,lbf
Unit stress switching	MPa,kPa,kgf/cm2,lbf/in2
Displacement unit	mm, cm, in
Force resolution	1/100000
Display resolution	0.001N
Machine schedule	800mm
Pressure plate size	800800800mm
Test speed	12.5mm/min
Software function	Chinese-English language exchange
Shutdown mode	Overload stop, emergency stop button, automatic stop for specimen damage, automatic stop for upper and lower limit setting.
Security equipment	Overload protection, limit element protection device
Power machine	AC variable frequency motor drive controller
Mechanical system	High precision ball screw
Power Supply	AC220V/50HZ~60HZ 4A
Machine weight	About 350KG
Performance characteristics	You can set the percentage fracture value, automatically stop the machine, enter the menu to select 4 different speeds, and get 20 results. You can view the average value of all test results and single results.
