Lab Testing Equipment Pen Core Circle Writing Tester

Place of Origin China
Brand Name SKYLINE
Certification calibration certificate
Model Number SL-PL001
Minimum Order Quantity 1 unit
Price Negoitable
Packaging Details Plywood case
Delivery Time 15 working days
Payment Terms Western Union, T/T,
Supply Ability 2 pcs/ month
Product Details
SKYLINE: Pen-Core Circle Writing Tester Number Of Samples: 8 / Time
Test Diameter: ≤26mm Pen Reciprocating Movement: Travel 100mm
Writing Angle: 60-90° Adjustable Dimension: 72cm*57cm*48cm
Weight: 60kg Packing Dimension: 79cm*64cm*71cm
Gross Weight: 90kg
Highlight:

50lb Lab Testing Equipment

,

180D Pen Core Lab Testing Equipment

,

180D Lab Testing Equipment
Product Description

ISO 27668-1 Write Test Machine for Detect Ballpoint Pens and Marker



Application

Can be used to detect ballpoint pens, neutral pen core, detection marker and whiteboard pen, can meet the two types of writing machine functions. The writing machine can detect the initial writing performance of the pen core, inking, line length, the written wear and other writing performance indicators, can also detect ink writing quality, is a pen factory, pen core factory, Ink factory indispensable testing equipment.



Principle

The machine simulates the state of writing with a pen, puts the sample on a certain load, and writes a circle mark at a certain speed to check whether the structure and performance of the sample are intact.



Main parameters

 Name

 Write Test Machine

 Manufacturers

 SKYLINE

 Number of samples

 8 / time

 Test Diameter

 ≤26mm

 The rotary speed of the core

 0-2 to min (digital input set)

 Pen reciprocating movement

 Travel 100mm

 Writing Speed

 0-10m/min (digital input settings)

 Paper Speed

 0-1000mm/min (digital input setting)

 Writing angle

 60-90°

adjustable

 Writing Length

 0-6000m

 Reminding function

 After testing the instrument automatically stop (the pen automatically lift)

 Paper-draw back function

 Instrument with paper collection

 Weight

 60kg

 Dimension

  72cm*57cm*48cm

 Packing Dimension

 79cm*64cm*71cm
 Gross weight   90





Pen-Core Circle Writing Tester.pdf
