Air Cylinder Controlled Furniture Testing Machine , Backrest Durability Testing Machine

Place of Origin CHINA
Brand Name SKYLINE
Certification Calibration certificate
Model Number SL-T33
Minimum Order Quantity 1 unit
Price negoitable
Packaging Details Plywood case
Delivery Time 35 work days
Payment Terms T/T, Western Union,
Supply Ability 1 unit
Product Details
SKYLINE: Backrest Durability Testing Machine Loading Weight: 102kg (225lb)
Standard: DIN 4551, EN 1335, NEN 1812 And BIFMA 5.1. Brand: SKYLINE
Cycle Rate: 5 ~ 15 Rotations Per Minute. Warranty: 18 Months
Highlight:

furniture testing machine

,

stability testing equipment
Product Description

BIFMA 5.1 Furniture Testing Equipment Air Cylinder Controlled Backrest Durability Testing Machine



This machine is to evaluate the ability of the chairs to withstand fatigue stresses and wear caused by rearward force on the backrest of the chair.


Specifications

 Backrest Height  500-1200mm
 Test speed  16 and 20 times/min or specified
 Loaded weight  100lb or 225 lb
 Counter  LCD, 0-999,999
 Air pressure force  0-150lb
 Machine size  136*66*140cm
 Force stroke  0-18 inch
 Weight  549kg
 Force angle  0-90°
 Power  1 #, AC220V, 3A


Testing Standards

  • ANSI/BIFMA X5.1-2011 10 Tilt Mechanism Test - Cyclic
  • ANSI/BIFMA X5.1-2011 15 Backrest Durability Test - Cyclic - Type I
  • ANSI/BIFMA X5.1-2011 16 Backrest Durability Test - Cyclic - Type II and Type III
