PLC Controlled Leather Testing Equipment Bally Leather Dynamic Waterproof Tester

Place of Origin China
Brand Name SKYLINE
Certification CE
Model Number SL-C72-B
Minimum Order Quantity 1 unit
Packaging Details plywood case
Delivery Time 15 working days
Payment Terms Western Union, , T/T
Supply Ability 1 pcs/ month
Product Details
SKYLINE: Bally Leather Dynamic Tester Test Speed: 90 ± 5cpm
Swing Angle: 30 ± 1 Two V-type Fixture Spacing: Two V-type Fixture Spacing: 60 ± 1mm60 ± 1mm
Dimensions: 500* 4200* 39mm Controller: PLC System Touch Screen Control
Highlight:

leather testing machine

,

rubber testing equipment
Product Description

PLC Controlled Leather Testing Equipment Bally Leather Dynamic Waterproof Tester



Product introduction

Used to test the leather, artificial leather, fabric water permeability, the use of flexing action to test the material penetration index.



Application

This tester is applied to do the waterproof test for leather, leather of imitation, cloth and others, the testing at the environment which surrounded the water and imposed the reverse, From that can measure the material index of resistant penetration.



Test method

Test method using clean steel beads placed in the material wrapped in the ball itself, the impedance and the total weight, must meet the requirements, under this condition measured material twists and turns waterproof penetration index, using the latest sensor components and special design, the test as long as the material Wrap water infiltration immediately stops automatically counting or when the set time (number of tests) arrives, it automatically stops and displays the time or number of times. With power off memory function.



Technical Parameters

 Number of tests  4sets
 Counter  LCD 0 ~ 999,999
 Test speed  90 ± 5cpm
 Swing angle  30 ± 1
 Two V-type fixture spacing  60 ± 1mm
 Controller  PLC system touch screen control
 Weight  55kg
 Power supply  AC220V 50HZ
 Volume  71 * 60 * 55cm



Leather Dynamic Waterproof Penetration Testing Mac...



PLC Controlled Leather Testing Equipment Bally Leather Dynamic Waterproof Tester
