Stainless Steel Flooring Materials Flammability Test Apparatus ISO 6925 BS 6307

Name: Stainless Steel Flooring Materials Flammability Test Apparatus ISO 6925 BS 6307
Brand: SKYLINE
SKU: SKYLINE
Rating: 4.9 (127 reviews)

Product Details

Place of Origin: CHINA

Brand Name: SKYLINE

Certification: CE

Payment & Shipping Terms

Minimum Order Quantity: 1 UNIT

Price: USD

Packaging Details: plywood case

Delivery Time: 35 work days

Payment Terms: T/T, Western Union, MoneyGram

Supply Ability: 1 unit/ month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                lab testing equipment, vertical flammability chamber


SKYLINE:	Flooring Materials Flammability Test Apparatus	Standards:	ISO 6925, BS 6307
Inner Box Size:	380x380x380mm	Volume (WxDxH):	20x25x48cm
Material:	Stainless Steel	Weight:	≈5.5Kg

SKYLINE:	Flooring Materials Flammability Test Apparatus
Standards:	ISO 6925, BS 6307
Inner Box Size:	380x380x380mm
Volume (WxDxH):	20x25x48cm
Material:	Stainless Steel
Weight:	≈5.5Kg

Product Description

ISO 6925, BS 6307 Flooring Materials Flammability Test Apparatus

Application
This machine is suitable for testing the surface burning performance of carpets under controlled laboratory conditions when exposed to small fire sources in a horizontal position.

Technical Parameters

Inner box size	380x380x380mm
Tablet method cover plate	230x230mm
Thickness	6.5mm
Intermediate hole diameter	205mm
Hot metal nut method cover	inner diameter 250mm
Metal nut	M16
Volume (WxDxH)	20x25x48cm
Weight (approx.)	≈5.5Kg

Features
1. Stainless steel box with refractory board inside
2. equipped with a viewing mirror to facilitate observation of samples
3. Provide standard metal sample plate
4.provide urotropine standard pills
5. can provide stainless steel nuts, can withstand 900 ° C high temperature

Test methods
Hot nut method: The stainless steel nut is heated to 900 ° C in a muffle furnace. The test sample is placed in the test box, and the clamp ring is placed on the sample with a pliers. The heated nut is placed in the center of the card ring. After 30 seconds, the nut is removed, and then the measurement can be performed to evaluate the sample. The spread of fire.
Urotropine Pill Method: The test sample is placed in the test box, the card ring is placed on the sample, the standard pill is ignited, and after the flame is extinguished, the measurement can be performed to evaluate the combustion effect.

Standards

ISO 6925；ASTM E648; CFR 1630/1631; BS 6307,BS 4790
