30 / min Footwear Testing Equipment BS3084 Zipper Reciprocating Fatigue Tester Machine

Place of Origin China
Brand Name SKYLINE
Certification CE
Model Number SL-F33
Minimum Order Quantity 1 unit
Packaging Details plywood case
Delivery Time 15 working days
Payment Terms Western Union, , T/T
Supply Ability 1 pcs/ month
Product Details
SKYLINE: Zipper Reciprocating Fatigue Tester Speed: 30/min
Force: 0-10 Kg Lateral Force. 0-5 Kg Longitudinal Force Angle: Open: 30degree. Close: 60degree
Dimension: 480 X 370 X600mm Weight: 65kgs
Standards: BS3084
Highlight:

abrasion resistance tester

,

rub resistance tester
Product Description

30 / min Footwear Testing Equipment BS3084 Zipper Reciprocating Fatigue Tester Machine



Product introduction

Zipper Tester, to determine the resistance to reciprocation of zipper (slide fastener), the test specimen is subjected to a specified number of cyclic operations whilst under lateral and longitudinal tension.
Zipper Tester catches the head of zipper to do reciprocating movement in a constant speed for 30 times per minute, integral counter to stop the drive when a pre-selected count has been reached



Specifications

 Horizontal fixture width  25mm
 Test speed  30cpm
 Reciprocating stroke  75mm
 Angle

 Open: 30degree.

 Close: 60degree
 Counter  LCD, 0-999999
 Power Supply  AC 220V 50/60HZ
 Dimensions  480 x 370 x600mm
 Weight  65kg
 Standard  CNS -1083 , BS 3084 , QB/T2171
 Standard accessories  1pc  60° Angle gauge
 1pc  30° Angle gauge
 8pcs  Positioning pieces
 1pc

 Power line

Zipper Reciprocation Tester.pdf
