Textile Fabrics Vertical Fire Testing Equipment
Textile Fabrics Vertical Fire Testing Equipment
Textile Fabrics Vertical Fire Testing Equipment
Textile Fabrics Vertical Fire Testing Equipment
Textile Fabrics Vertical Fire Testing Equipment

Textile Fabrics Vertical Fire Testing Equipment

Product Details

Place of Origin: CHINA

Brand Name: SKYLINE

Certification: CE

Model Number: SL-F15

Payment & Shipping Terms

Minimum Order Quantity: 1 unit

Price: neogitable

Packaging Details: plywood case

Delivery Time: 10 working days

Payment Terms: T/T, Western Union, MoneyGram

Supply Ability: 1 unit / month

Get Best Price

Product Details

Product Description
Product Details
Highlight:

flammability test chamber

,

flammability test apparatus

SKYLINE:
Vertical Flammability Tester
Standard:
CFR 1615/1616 STANDARD FOR THE FLAMMABILITY OF CHILDREN'S SLEEPWEAR
Diameter Of Burner Opening:
Φ11mm ± 0.3mm Igniter
Dimension:
35 Cm X 40 Cm X 205 Cm
Burning Angle::
25° Or 90°
Flame Height:
30mm ± 2mm To 50mm±2mm (adjustable)
SKYLINE:
Vertical Flammability Tester
Standard:
CFR 1615/1616 STANDARD FOR THE FLAMMABILITY OF CHILDREN'S SLEEPWEAR
Diameter Of Burner Opening:
Φ11mm ± 0.3mm Igniter
Dimension:
35 Cm X 40 Cm X 205 Cm
Burning Angle::
25° Or 90°
Flame Height:
30mm ± 2mm To 50mm±2mm (adjustable)
Product Description
Textile Fabrics Vertical Fire Testing Equipment CFR 1615/1616 For Knitted Fabric

Application
Textiles vertical flammability test apparatus is applied to test the burning behaviour of woven fabric, knitted fabric, coated fabric and Laminated products. The equipment is designed according to JIS1091-1992.

Standards
CFR 1615/1616 standard for the flammability of children's sleepwear
CA TB117 Requirements, Test Procedure and Apparatus for Testing the Flame Retardance of Resilient Filling Materials Used in Upholstered Furniture
ASTM D6413 Standard Test Method for Flame Resistance of Textiles (Vertical Test)
ISO6940/6941 –Textile fabrics- Burning behavior-Measurement of flame spread properties of vertically oriented specimens

Specification
 Burner  Φ11mm ± 0.3mm igniter
 Burning angle  25° or 900
 Flame height  30mm ± 2mm to 50mm±2mm (adjustable)
 Burning time  0-999.9s±0.1s (adjustable)
 Afterflame time  0-999.9s±0.1s
 Afterglow time  0-999.9s±0.1s
 Burning gas  98% propane gas
 Clamps  U-sharp clamp, (L)422*(W)89*(TH)2mm, interior size: 356*51mm
 Weights  54.5g, 113.4g, 226.8g, 340.2g, 453.6g each one
 Working size
 (W)329*(D)329*(H)767mm
